Description

This pseudo cylindrical equal area projection is primarily used for thematic maps of the world. Also known as Putnins P4.

Illustration of Craster Parabolic projection


Projection method

Pseudo cylindrical.


Linear graticules

The central meridian is a straight line half as long as the equator. Parallels are unequally spaced, straight parallel lines perpendicular to the central meridian. Their spacing decreases very gradually as they move away from the equator.


Properties


Shape



Free of distortion at the central meridian at 36°46' N and S. Distortion increases with distance from these points and is most severe at the outer meridians and high latitudes. Interrupting the projection greatly reduces this distortion.

Area



Equal area.

Direction



Local angles are correct at the intersection of 36°46' N and S with the central meridian. Direction is distorted elsewhere.

Distance



Scale is true along latitudes 36°46' N and S. Scale is also constant along any given latitude and is symmetrical around the equator.


Limitations

Useful only as a world map.


Uses and applications

Thematic world maps.


Parameters


Desktop





Workstation
